Aircraft Ipanema 201
- Stainless Steel System.
- Options for Tubes, Filters, and Bars with wall thickness of 1.5 mm or 2 mm.
- New Brake System for Pump.
- New Blade model for Windmill Pump with length up to 165 mm.
- Windmill Pump available in two model options.
- Windmill Pump with options of 4, 6, or 8 blades.
- Bar options in 1 1/4" or 1 1/2".
Number: | Product: | PN: |
|---|---|---|
1 | Gatebox | (PN01618) |
2 | Quick Hose Coupling | (PN85283NX) |
2 | Quick Hose Coupling | (PN85283NX) |
3 | Windmill Pump 4 Blades | (PN01639FT-XX-4P) |
3 | Windmill Pump 6 Blades | (PN01639FT-XX-6P) |
3 | Windmill Pump 8 Blades | (PN01639FT-XX-8P |
4 | Bypass Valve | (PN01725H7) |
5 | Connection Tube Bypass – Y Filter
| (PN01711H7-2) |
6 | Y Filter | (PN01729H7) |
7 | Quick Hose Coupling 2″ 45° | (PN01013NX) |
8 | Bypass Valve 45° | (PN01725H7/45)
|
9 | Bypass Valve with Flowmeter Filter | (PN01725H7/F) |
10 | Housing Box Outlet Flange | (PN01712)
|
11 |
Shut-off Valve 2″ | (PN01734) |
12 | Flowmeter Filter | (PN01708H7/VALV)
|
13 | Flowmeter Filter | (PN01734) |
14 | 2″ Supply Tube | (PN01710H7-2)
|
15 | 2″ Internal Supply Tube | (PN01062H7) |
16 | Airfoil Bar | (PN01731H7R-202) – 1 1/4″ Nozzle (PN01731H7R-202) – 1 1/2″ Nozzle (PN01732H7R-202-1/8) – 1 1/2″ Rotary (PN01732H7R-202-1/4) – 1 1/2″ Rotary |
17 | Bar Support | (PN01765H7) |
18 | Hopper Flange | (PN01755/01756) |
19 | Windmill Pump Support | (PN01603) |
20 | Bypass Control Rod | (PN01209) |
21 | Swivel Joint | (PN01262) |
22 | 2″ Supply Valve L | (PN01726H7) |
23 | 2″ Supply Valve R | (PN01753H7) |
27 | Housing Control Rod
| (PN01453) |
