Aircraft Ipanema 202
- Stainless Steel System.
- Tubing, Filters, and Bars: Available in wall thicknesses of 1.5mm or 2mm.
- Brake System Upgrade: Enhanced braking mechanism for the pump.
- New Wind Pump Blade Model: Blade length up to 165mm.
- Two Wind Pump Models: Offering flexibility for different needs.
- Blade Options: Configurable with 4, 6, or 8 blades.
- Bar Size Options: Available in 1 1/4" or 1 1/2" diameters.
Number: | Product: | PN: |
|---|---|---|
1 | Gatebox | (PN01618) |
2 | Quick Coupling Hose | (PN85283NX) |
2 | Quick Coupling Hose | (PN85283NX) |
3 | 4-Blade Wind Pump | (PN01639FT-XX-4P) |
3 | 6-Blade Wind Pump | (PN01639FT-XX-6P) |
3 | 8-Blade Wind Pump | (PN01639FT-XX-8P |
4 | Bypass Valve | (PN01725H7) |
5 | Bypass Connection Tube – Y-Filter | (PN01711H7-2) |
6 | Y-Filter | (PN01729H7) |
7 | 2″ 45° Quick Coupling Hose | (PN01013NX) |
8 | 45° Bypass Valve | (PN01725H7/45)
|
9 | Bypass Valve with Flow Meter | (PN01725H7/F) |
10 | Dump Valve Box Outlet Flange | (PN01712)
|
11 | 2″ Shutoff Valve | (PN01734) |
12 | Flow Meter Filter | (PN01708H7/VALV)
|
13 | Flow Meter Filter | (PN01734) |
14 | 2″ Supply Tube | (PN01710H7-2)
|
15 | Internal 2″ Supply Tube | (PN01062H7) |
16 | Aerofoil Bar | (PN01731H7R-202) – 1 1/4″ NOZZLE (PN01731H7R-202) – 1 1/2″ NOZZLE (PN01732H7R-202-1/8) – 1 1/2″ ROTARY (1/8 turn) (PN01732H7R-202-1/4) – 1 1/2″ ROTARY (1/4 turn) |
17 | Bar Mount | (PN01765H7) |
18 | Hopper Flange | (PN01755/01756) |
19 | Wind Pump Mount | (PN01603) |
20 | Bypass Control Rod | (PN01209) |
21 | Guinhol | (PN01262) |
22 | 2″ Supply Valve (Type E) | (PN01726H7) |
23 | Supply Valve (Type D) | (PN01753H7) |
24 | Longeron Support | (PN91202) |
25 | Longeron Support | (PN91203) |
26 | Longeron Support | (PN91204) |
27 | Dump Control Rod | (PN01453) |
