Aircraft Air Tractor 402
- Stainless Steel System.
- Tube, Filter and Bar options with 1.5mm or 2mm wall thickness.
- New Brake System for Wind Pump.
- New Blade model for Wind Pump with length up to 220mm.
- Wind Pump with two Rotor size options (Large and Small).
- Wind Pump with 4, 6 or 8 blade options.
- Bar options in 1 1/4" or 2".
1
2
3
4
5
6
7
8
9
10
10
11
11
12
12
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
29
30
31
Number: | Product: | PN |
|---|---|---|
1 | Jettison Box | (PN90003/H1) |
2 | 3″ 90° Hose Quick Coupling | (PN01823NX) |
3 | 3″ Inlet Pipe | (PN01821H7) |
4 | 4-Blade Wind Pump | (PN20808-XX-4P) |
4 | 6-Blade Wind Pump | (PN20808-XX-6P) |
4 | 8-Blade Wind Pump | (PN20808-XX-8P) |
5 | Pump Connection Pipe – By Pass | (PN01822H7-90113H7)
|
6 | 3″ Supply Pipe | (PN01819H7-90111H7) |
7 | By Pass Valve | (PN01115) |
8 | Y Filter 402 | (PN01810/40) (PN01810/90) |
9 | By Pass Rod | (PN90001) |
10 | Y Filter Fixing Rod | (PN90003/H1)
|
11 | Y Filter Fixing Rod | (PN90003/H2) |
12 | Engate Rápido Mangueira 3″ 90° | (PN85283NX) |
13 | Aerodynamic Bar | (PN01813R) (PN07064R OU 01817R-1/4) (PN01817R) (PN07065R OU 07065R-1/4) |
14 | 3″ Inlet Pipe + Shut-off Valve | (PN01821H7)
|
15 | 3″ Supply Valve (L) | (PN90107/402/502/602/E) |
16 | Left Y Filter Support | (PN90003/P2 402 ESQUERDO) |
17 | Left Y Filter Support | (PN90003-90109/P1 ESQUERDO) |
18 | 3″ Supply Valve (R) | (PN90107/402/502/602/D) |
19 | Right Y Filter Support | (PN90003/P2 402 DIREITO) |
20 | Right Y Filter Support | (PN90003-90109/P1 DIREITO) |
21 | Bar Support | (PN90004/BAIXA) (PN90004/ALTA) |
22 | Pump Connection Pipe – By Pass with Filter | (PN90180)
|
23 | Wind Pump Support | (PN90005/INF) |
24 | Wind Pump Support | (PN90005/SUP)
|
25 | By Pass Support Plate | (PN90181) |
26 | Rod | (PN90182)
|
27 | Rod | (PN90183)
|
28 | 3″ Supply Pipe | (PN01816H7) |
29 | Support Plate | (PN90184) |
30 | 3″ Double Supply Pipe | (PN05053 P1 E P2) |
31 | Y By Pass Pipe | (PN90200) |
