Aircraft Air Tractor 602
- Stainless Steel System.
- Options for Tubes, Filters, and Bars with 1.5mm or 2mm wall thickness.
- New Brake System for Wind Pump.
- New Blade model for Wind Pump with lengths up to 220mm.
- Wind Pump available in two Rotor sizes (Large and Small).
- Wind Pump available with 4, 6, or 8 blade configurations.
- Bar options in 1 1/4" or 2".
1
2
3
4
4
4
4
5
6
7
8
9
10
11
12
13
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
Number | Product | PN |
|---|---|---|
1 | Jettison Box AT 602/802 | (PN90043)
|
2 | 3″ Hose Quick Coupling | (PN01514NX) |
3 | Bomba Eólica AT 602/802 – 4 Pás
| (PN20809- X -XX-4P) |
3 | Bomba Eólica AT 602/802 – 6 Pás
| (PN20809 – X -XX-6P) |
4 | 2 1/2″ Hose Quick Coupling | (PN85284NX) |
5 | By Pass Valve | (PN90015) |
6 | 3″ 90° Hose Quick Coupling | (PN90223/40) (PN90223/90) |
7 | Aerodynamic Bar | (PN05615R) (PN05617R OU 05617R-1/4) (PN05619R) (PN05620R OU 05620R-1/4) |
8 | By Pass Rod | (PN90114) |
9 | Right Y Filter Support | (PN90109/P2 DIREITO) |
10 | Right Y Filter Support | (PN90109/P1/DIR)
|
11 | Left Y Filter Support | (PN90003-90109/P1 ESQUERDO) |
12 | Left Y Filter Support | (PN90109/P2 602 ESQUERDO) |
13 | Y Filter Fixing Rod | (PN90109/H1) |
14 | Y Filter Fixing Rod | (PN90109/H2) |
15 | Pump Connection Pipe – By Pass | (PN90188H7) |
16 | Support Plate Connection Pipe – By Pass | (PN05623/UNICO) |
17 | 3″ Supply Valve (L) | (PN90107/402/502/602/E) |
18 | By Pass Support Plate | (PN90181) |
19 | 3″ Supply Valve (R) | (PN90107/402/502/602/D) |
20 | Double Supply Pipe | (PN05623/DUPLO) |
21 | Y By Pass Pipe | (PN90189) |
22 | Bar Support | (PN90115/BAIXA) (PN90115/ALTA) |
23 | Wind Pump Support | (PN90005/INF)
|
24 | Wind Pump Support | (PN90005/SUP) |
25 | Rod | (PN90183)
|
26 | Rod | (PN90182)
|
27 | Pump Connection Pipe – By Pass with Filter | (PN90190) |
28 | Shut-off Valve | (PN05611)
|
29 | Outlet Flange | (PN90046/602-802) |
