Aircraft Air Tractor 802
- Stainless Steel System.
- Options for Tubes, Filters, and Bars with wall thickness of 1.5mm or 2mm.
- New Brake System for Windmill Pump.
- New Blade Model for Windmill Pump with lengths up to 220mm.
- Windmill Pump available with two Rotor sizes (Large and Small).
- Windmill Pump available with 4, 6, or 8-blade options.
- Bar options in 1 1/4" or 2".
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
19
20
20
21
21
22
23
24
25
26
27
28
29
30
Number: | Product: | PN: |
|---|---|---|
1 | Jettison Box AT 602/802 | (PN90043)
|
2 | 3″ Inlet Pipe | (PN90012H7) |
3 | 3″ Quick Hose Coupling | (PN01514NX) |
4 | Windmill Pump AT 602/802 – 4 Blades | (PN20809- X -XX-4P) |
4 |
Windmill Pump AT 602/802 – 6 Blades | (PN20809 – X -XX-6P) |
5 | 2 1/2″ Quick Hose Coupling | (PN85284NX) |
6 | 3″ Supply Pipe | (PN90011H7) |
7 | 3″ Supply Pipe | (PN90010H7) |
8 | Bypass Valve | (PN90015) |
9 | Y Bypass Pipe | (PN90191)
|
10 | Y Filter 802 | (PN90016/40) (PN90016/90) |
11 | 3″ Supply Valve (E)
| (PN90107-802-E) |
12 | 3″ Supply Valve (D) | (PN90107-802-D) |
13 | 3″ Dual Supply Pipe | (PN005054)
|
14 | Spray Boom
| (PNXXXXXR) (PNXXXXXR OU XXXXXR-1/4) (PNXXXXXR) (PNXXXXXR OU XXXXXR-1/4) |
15 | Boom Mount | (PN90018)
|
16 | Bypass Rod | (PN90114)
|
17 | Right Y Filter Bracket | (PN90009/P2 DIREITO)
|
18 | Right Y Filter Bracket
| (PN90009/P1) |
19 | Left Y Filter Bracket | (PN90009/P2 ESQUERDO) |
20 | Y Filter Fixing Rod | (PN90009/H1) |
21 | Y Filter Fixing Rod
| (PN90009/H2)
|
22 | Pump-to-Bypass Pipe | (PN90014H7)
|
23 | Pump-to-Bypass Pipe | (PN90014H7/-802-VALV)
|
24 | Bypass Support Plate | (PN90181)
|
25 | Windmill Pump Bracket
| (PN90005/INF)
|
26 | Windmill Pump Bracket | (PN90005/SUP)
|
27 | Rod | (PN90182) |
28 | Rod | (PN90183)
|
29 | Shut-Off Valve
| (PN05611) |
30 | Outlet Flange | (PN90046/602-802)
|
