Thrush 510 Aircraft
- Stainless Steel System.
- Options for Tubes, Filters, and Booms with wall thickness of 1.5 mm or 2 mm.
- New Brake System for Wind Pump.
- New Blade Model for Wind Pump with length up to 220 mm.
- Wind Pump available in two Rotor size options (Large and Small).
- Wind Pump with 4-, 6-, or 8-blade options.
- Boom options in 1 1/4" or 2".
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
Number: | Product: | PN: |
|---|---|---|
1 | Thrush Housing Box | (PN05072) |
2 | 3″ Quick Coupling for Hose | (PN01514NX) |
3 | 4-Blade Wind Pump | (PN05033X-XX-4P) |
3 | 6-Blade Wind Pump | (PN05033X-XX-6P) |
3 | 8-Blade Wind Pump | (PN05033X-XX-8P) |
4 | 2″ Thrush By-Pass Valve | (PN01725) |
5 | By-Pass Connection Tube – Y Filter | (PN05077) |
6 | Y Filter Thrush 510 | (PN05035/FILTRO4″) |
7 | Y Filter Thrush 510
| (PN05035/FILTRO4″) |
8 | 3″ Supply Tube | (PN05071) |
9 | 3″ Supply Valve | (PN05034) |
10 | Thrush Spray Boom | (PN07067R) (PN05036R OU 05036R-7/4) (PN007859R) (PN05406R OU 05406R-7/4) |
11 | Thrush Spray Boom | (PN05081/P1) |
12 | Thrush Boom Support | (PN05081/P2) |
13 |
By-Pass Control Rod | (PN05076) |
14 | Housing Box Outlet Flange | (PN90046) |
15 | Y Tube Thrush 510 | (PN05035) |
16 | Inline Filter
| (PN05078) |
17 | Wind Pump Support | (PN90005/INF) |
18 | Wind Pump Support | (PN90005/SUP) |
19 | Pump Tube – By-Pass
| (PN05075) |
20 | Left Y Filter Bracket | (PN05079/ESQ) |
21 | Right Y Filter Bracket
| (PN05079/DIR) |
22 | 3″ Shut-Off Valve
| (PN05079/BORB) |
23 | By-Pass Connection Tube – Y Filter
| (PN05077/C) |
